描述
Rated capacity: 1kVA~1000kVA
Rated voltage: 660V, 480V, 380V, 220V, 200V, etc.
Rated frequency: 50Hz, 60Hz
Connection group: Y, yn0, Y, d11, D, yn11, etc.
Protection level: IP00, IP20
Insulation level: Class B, Class F, Class H
Usage environment:
Altitude: ≤1000m
Adapt to ambient temperature: -10~+45℃
Adapt to relative temperature: ≤95% at 26℃
Usage environment: indoors (when used outdoors, please provide the protection level)
Structure:
The iron core is carefully stacked with high-quality cold-rolled silicon steel sheets. According to the different insulation levels, the entire core is impregnated with insulating paint of different insulation levels, which can effectively reduce the noise of the transformer and reduce the impact of salt spray, mold, etc. on the transformer. Depending on the protection level, the transformer box is made of high-quality steel plates. The structure not only fully considers air circulation, but also effectively plays a protective role. The transformer wiring cables are also easy to connect, and the design is full of humanization. Voltage ammeter, power indicator light, molded case circuit breaker, etc. can be installed according to user requirements.
download Google:
Product model Rated capacity Rated voltage
Working method Insulation level Protection level
Other special requirements will be specified in the technical agreement.
The price in the picture is for reference only and does not constitute a transaction price. The actual product shall prevail.
Why Choose us?
We have special professional technical team to inspect each machine before shipping to client.
We have whole sources in China for both new and used transformers with over 30 years working experience.
We are family heritage group which good reputation is very important for our family.
